V-tech Power Hydraulics

Hydraulic Bearing Puller (2 Jaws Kit)




With the assistance of our excellent logistics facility, we are able to deliver the orders within the postulated time frame. Owing to the immense and well-maintained storage space, we efficiently keep the wide assortment of products in safe place to ensure complete safety. Our automated storage space helps us in maintaining the quality standards as well.



Capacity : 6 - 12 Tons



Features :

  • Self-contained Hydraulic Puller, no need for extra hand pump, hose and coupling, allows operating by one person.
  • 360° Rotary handle swivel clevis allows pumping at all directions.
  • Edges of knife-like design of separator allow removing hard-to-grip parts easily.
  • Safety valve minimizes the risk of the puller overload by limiting the applied force.
  • Complete hydraulic puller allows effortless generation of force and dismounting.
  • The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.
  • Forging parts and special treatment provide long life service and the best strength.
  • A complete pulling package, all contained in a convenient carrying case.


Specifications

Output (Ton Max) Item   No. Reach (mm) Spread (mm) Stroke (mm) Jaw Tip (mm)  Net Weight (Kgs) Gross Weight (Kgs)
6 Tons CK-605 190/300 90/210 82 15 7 24 12.55 15.05
10 Tons CK-605 Extra 190/300 90/210 82 15 7 24 12.45 14.95
8 Tons CK-805 245/300 90/210 82 15 7 24 13.66 16.16
12 Tons CK-805 Extra 245/300 90/210 82 15 7 24 13.5 17.95
