V-tech Power Hydraulics

SPE-3000 Series Hydraulic Electric Pump




Specifications:

  • Requires less energy, simple and easy to operate.
  • Suitable for any industrial operations.
  • Handle and casing built together.
  •  Equipped with 10ft remote line.
  • Carbon brush less motor, working frequently.
  • Reservoir capacity: 3000-6000c.c.
  •  Flow at rated pressure: 4-0.4L.
  • Motor Size 0.37KW (0.5 HP).
  • Maximum operating pressure 700bar.


Specifications

Model No. Usable Oil Cap. (cm3/ltrs) Power (kW/hp) Motor Voltage (Volts) Pressure Rating (psi/bar) Output flow rate (L/min) dBA at Idle & 700 bar Weight (Include all) (Kg)
1st Stage 2nd Stage 1st Stage 2nd Stage
SPE-3000A 3000/3 0.37 (0.5) 115/230 200/14 10, 000 / 700 4 0.4 85-90 16
SPE-3000B 3000/3 0.37 (0.5) 115/230 200/14 10, 000 / 700 4 0.4 85-90 16
SPE-3000C 3000/3 0.37 (0.5) 115/230 200/14 10, 000 / 700 4 0.4 85-90 16
SPE-3000LT 6000/6 0.37 (0.5) 115/230 200/14 10, 000 / 700 4 0.4 85-90 24



Note :

  • All above models are available for double acting applications also.
  • For Double acting Cylinder :Pump with 4 way Valve Example : SPE-3000D
